DESCRIPTION

Informations de base.

Numéro de modèle.	HCM-30W
Niveau d'entrée audio	-15 ~ +15 sélectionné par pas de 0,1 dBm via le panneau
Source de courant	AC220V
Interface d'entrée audio analogique	Tête XLR femelle XLR
Rapport signal/bruit (modulation 100 %)	83,6 dB
Séparation des canaux gauche et droit	65,4dB
Fréquence de transmission nominale	87-108
Puissance de sortie	100W
Forfait Transport	Boîte d'emballage d'exportation
Marque déposée	NJZR
Origine	Nankin, Jiangsu
Capacité de production	Personnalisation à la demande

Description du produit

Main features:★ All solid-state design, digital analog compatibility;★ Professional broadcasting level exciter;★ All power amplifiers are made of high-power LDMOS tubes produced by PHILIPS;★ Wideband amplification of power amplifier components;★ The modulation method is digital DDS modulation★ Input interface: 2 analog audio interfaces, 1 digital audio interface, 1 SCA/RDS interface, 1 1PPS interface, and 1 10MHz clock interface;★ Output interface: 1 LOCK IN interface, 1 RS232 interface, 1 RS485 interface, 1 RJ45 interface, 1 RF monitoring interface, and 1 RF power output interface;★ Large screen LCD display in Chinese, displaying the intensity of left and right channel signals through the fluctuation of two sound columns inside the LCD screen;The parameters displayed through the LCD include: emission power, reflection power, current of the amplifier tube, voltage of the amplifier tube, input level, temperature, and loop voltage;★ Indicate the above content through indicator lights: power indicator light, overvoltage protection indicator light, standing wave ratio alarm indicator light, remote control status indicator light, temperature alarm indicator light, overcurrent, circuit, overvoltage exceeding limit indicator, system communication fault
